| Part Number | Current Rating | Voltage Rating | Interrupting Rating | Mounting Hole Dimension |
Mounting Hole Qty |
* |
Material |
|---|---|---|---|---|---|---|---|
| ANL-B-020 | 20A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Zinc Alloy |
| ANL-B-030 | 30A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Zinc Alloy |
| ANL-B-035 | 35A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Zinc Alloy |
| ANL-B-040 | 40A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Zinc Alloy |
| ANL-B-050 | 50A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Zinc Alloy |
| ANL-B-060 | 60A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Zinc Alloy |
| ANL-B-070 | 70A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Zinc Alloy |
| ANL-B-080 | 80A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Zinc Alloy |
| ANL-B-100 | 100A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Zinc Alloy |
| ANL-B-120 | 120A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Zinc Alloy |
| ANL-B-125 | 125A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Zinc Alloy |
| ANL-B-130 | 130A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Zinc Alloy |
| ANL-B-150 | 150A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Zinc Alloy |
| ANL-B-175 | 175A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Zinc Alloy |
| ANL-B-200 | 200A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Zinc Alloy |
| ANL-B-225 | 225A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Brass |
| ANL-B-250 | 250A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Brass |
| ANL-B-275 | 275A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Brass |
| ANL-B-300 | 300A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Brass |
| ANL-B-325 | 325A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Copper |
| ANL-B-350 | 350A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Copper |
| ANL-B-400 | 400A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Copper |
| ANL-B-450 | 450A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Copper |
| ANL-B-500 | 500A | 32V | 2700A@32V | M8 | 2 | ● | Bakelite, Imitation Gold-Plated Copper |
